Woodworking Jig for Cam Fittings and Dowels | 32 mm System | Steel Bushings | 18 mm Panel

DRILLING GUIDE FOR CAM FITTINGS AND DOWELS

Are you tired of measuring holes for cam fittings and correcting joints?
This jig allows you to drill
quickly • precisely • consistently
when assembling furniture components.

Thanks to the steel guide bushings, it ensures precise positioning of holes for cam fittings and dowels, significantly accelerating furniture assembly and increasing work precision.

🧰 Key Features

✅ steel guide bushings – high durability and drilling accuracy

✅ designed for 18 mm furniture panels

✅ side stop enables quick positioning relative to the panel edge

✅ possibility of stable clamping during operation

✅ drilling axis marking facilitates quick jig setup

✅ reinforced construction ensuring drilling repeatability

✅ compact and convenient to use

📐 Technical Specifications

• Jig dimensions: 130 × 80 × 40 mm
• Hole spacing: 32 mm
• Drill guide diameters: 15 mm / 5 mm / 8 mm
• Cam distance from board front: 34 mm
• Cam distance from board edge: 50 mm
• Bushings: steel
• Dimensional tolerance: ±0.1 mm

🎯 How to Use?

You set the jig → you drill → you assemble the component.

✔ quick hole drilling
✔ perfect component fit
✔ drilling repeatability

Ideal for woodworking, furniture making, and assembly tasks.
